Folding resistance C1S Folding box board / coated paperboard 300gsm
for making box
Product description
Folding box board ( FBB ) is a type of boxboard with a glossy coated surface
on one side for superior printability. FBB have a good stiffness
and smoothness.
It is typically used as packaging material for small boxes that
require high quality printability, such as
consumer electronic products, cosmetics or other consumer
merchandise. We classifies different classes
of products,so as to cater to the different needs of the customers.
1) paper type
|
Folding box board ( two side white)
|
2) Grammage
|
210gsm 230gsm 250gsm 300gsm 350gsm 400gsm
|
| 3) Roll size |
width: 635 / 660 / 686 / 711 / 737 / 787 / 838 / 889 / 914 / 961 /
1016
/ 1041 / 1092 / 1194mm |
4) Sheet size
| 787*1092mm / 889*1194mm and accept cut by paper roll |
| 5) MOQ |
5MT for special size (customized), and 1MT for standard size ( like
787*1092mm / 889*1194mm ) At least 1 full container per order
|
| 6) Loading |
25tons for 40GP, 15~16tons for 20GP
|
| 7) shipment terms |
FOB , CFR,CIF are available
|
| 8) Payment terms |
T/T---30% advance as desposit,70% Before Loading ( FOB terms) |
Data sheet
| Items | Unit | Folding box board (FBB) |
| Substance | Gsm | 210±4 | 230±4 | 250±4 | 300±4 | 350±4 | 400±4 |
| Thickness | | 270±10 | 305±10 | 335±10 | 410±10 | 480±10 | 540±10 |
| Brightness | % | 88±1.5 |
| Bulk | CM3/g | 1.29 | 1.33 | 1.34 | 1.37 | 1.37 | 1.35 |
| Stiffness Taber MD | mNm | ＞4.5 | ＞6.5 | ＞8.0 | ＞14 | ＞22 | ＞30 |
| Stiffness Taber CD | mNm | ＞2.6 | ＞3.2 | ＞4.2 | ＞7.0 | ＞10.5 | ＞14.8 |
| Moisture | % | 8.3±0.3 |
| SurfacePrinting Intensity | m/s | ≥1.8 |
| Folding Endruance | times | ≥15 |
Usage :
1. Packaging material for small boxes, like food, wine, toy, drug,
shoe boxes and others.
2. Widely used and supplied in printing area, single side color
printing, then make cartons which are used
as packaging, or used in the design, manual products.
3. Also can be used as a commodity tag, plate and blister
packaging.
Feature
1.) 100% virgin wood pulp quality
2.) High smoothness and full colors offset printability
3.) Strong folding resistance
4.) High bulky thickness
5.) Standard export packing and professional services
Packing and Loading
1. In Sheets: bulk packed on strong wooden pallets wrapped with PE
film,
4 angles protected. Waterproof film.
2. In Ream: Normally 100sheets per ream. Ream packed wrapped with
PE film,
4 angles protected. Waterproof film.
3. In Rolls: PE film wrapped or kraft paper wrapped.
4. One 20ft can fit into about 15~16 tons, more or less depend on
the size.
5. One 40ft can fit into about 25tons, more or less depend on the
size
| Grammage | Sheets/ Ream | Sheets/ Pallet |
| 210g | 125 | 3500 |
| 230g | 125 | 3000 |
| 250g | 125 | 2750 |
| 300g | 100 | 2300 |
| 350g | 100 | 2000 |
| 400g | 100 | 1800 |
Our advantage
1. We can provide different grade of paper board for your choose.
2. Except the standard size, we can also accept special size, and
the MOQ is 5 tons for per size.
3. Paper sample is allowed, if you need to test let us know, you
can also come to visit our factory see
more different sample.
4. Strictly quality contriol in each precessing when producing coated
duplex board paper
5.We have rich experience over 13 years for trading paperboard
6. We can provide different kind of paper for your choice
| Duplex board with grey back | 230gsm ~450gsm |
| Duplex board wihth white back | 250gsm ~450gsn |
| Folding box board | 210gsm ~400gsm |
| C2S art paper / Art card | 80gsm ~450gsm |
Paper sample :
---we can provide paper sample free with A4 size, if you need other
big size you can let me know,
we will try our best to meet your requirement.
